Mineral Wool Blanket
| Technical Data |
| Properties | Blanket | Standards |
| Density Tolerance | ±10% | GB/T 19686-2005 |
Fire Performance
| Non-Combustible | GB/T 5464-1999 |
| Reaction to fire Class A1 | GB/T 8624-2006 |
| Thermal Conductivity(W/mK,at70±5℃) | ≤0.044 | GB/T 10295 |
| Fiber Diameter | 7(+/-1)um | GB/T 5480. 4 |
| Shot Content(shot size>0.25mm) | ≤12% | - |
| Moisture Content | ≤0.5% | - |
| Organic Matter Content | ≤4% | - |
| Melting Point | >1000℃ | - |
Main application:
Metallurgical field: In the metallurgical industry, rock wool is used for heat
preservation and insulation of various
high-temperature equipment. For example, the use of rock wool in
smelting furnaces, heating furnaces and other
equipment can effectively reduce heat loss, improve the thermal
efficiency of the equipment, and also reduce
energy consumption and production costs.
Ship field: In the ship field, rock wool is used for thermal insulation of
hulls, cabins and machinery and equipment.
It can effectively maintain the temperature in the cabin and
improve the living and working environment of the crew.
Advantage:
- Thermal Insulation
- Fire Safety
- Acoustic Control
- No Corrosion
- Environmental friendly
- Moisture Resistance
- Energy Conservation & Emissions Reduction
Specification:
| Product | Blanket |
| Density (kg/m3) | 60-100 |
| Size :L x W (mm) | 600X5000 |
| Thickness (mm) | 30-150 |
Product introduction of the stone wool Blanket
FANRYN Stone wool blanket is made from natural rocks such as basalt and limestone. The rocks are
melted in
a cupola at temperature of >1450 ℃, and the molten lava is fiberized by a spinner. The inorganic fibers are bonded
together using a thermosetting resin to form the final product which is cut into suitable sizes
for easy handling and
installation.
STONE WOOL blanket is widely used in public, commercial and residential buildings as well as industrial plants,
for applications such as roofing, external wall, partition wall and floating floor to provide fire protection, thermal insulation,
acoustic control and condensation control.
