Product Description:
The fiberglass insulation for piping is made from glass wool, a
highly effective material that offers superior thermal insulation.
It is specifically designed to prevent heat transfer and improve
energy efficiency in any tube system. With its exceptional
fireproof properties, this insulation material can also help reduce
the risk of fire and improve safety in your facility.
Our fiberglass pipe insulation product is not only highly efficient
but also easy to install. It comes in pre-cut sizes that fit most
standard pipe sizes, so installation is quick and hassle-free.
Simply wrap the insulation around the pipe, secure it in place with
adhesive or tape, and you're done.
Whether you need to protect your pipes from extreme heat or reduce
noise levels in your facility, this insulation material is the
perfect solution. Its superior thermal insulation properties ensure
that heat is kept inside the pipes, preventing heat loss and
reducing energy costs. Additionally, its sound insulation
properties make it ideal for use in noisy environments, such as
HVAC ducts and ventilation systems.
If you're looking for an insulation material that can provide both
thermal and sound insulation, look no further than our fiberglass
pipe insulation product. With its exceptional fireproof properties,
easy installation, and superior performance, it is the perfect
choice for any tube system.
Product parameter of the thermal insulation pipe
Recommend Thickness List(mm)
| Pipeline System Type | The Thickness of glasswood pipe shell applied in different pipeline
(mm) |
| Liquid Temperature Range ℃ | Diameter of Branches Under 50mm | Under 25mm | 32-50 | 64-100 | 125-150 | Above 200mm |
| Air System Steaming and Water System High Temperature/ High
Pressure System | 152-238 | 40 | 64 | 64 | 75 | 89 | 89 |
| Medium Temperature/ Medium Pressure System | 122-151 | 40 | 50 | 64 | 64 | 75 | 75 |
| low Temperature/ low Pressure System | 94-121 | 25 | 40 | 40 | 50 | 50 | 50 |
| low Temperature System | 49-93 | 13 | 25 | 25 | 40 | 40 | 40 |
| Steaming Condensator of Watering System | Any Temperature | 25 | 25 | 40 | 50 | 50 | 50 |
Equivalent Thickness of Surface Cooling Prevention
| Environment Temperature | Relative Humidity | System Working Temperature |
| 2℃ | 7℃ | 13℃ |
| 38℃ | 50%-60% | 25 | 25 | 25 |
| 70% | 40 | 30 | 30 |
| 80% | 75 | 60 | 50 |
| 85% | 100 | 90 | 75 |
| 32℃ | 50%-60% | 25 | 25 | 25 |
| 70% | 25 | 25 | 25 |
| 80% | 50 | 50 | 40 |
| 85% | 80 | 75 | 60 |
| 27℃ | 50%-70% | 25 | 25 | 25 |
| 80% | 50 | 40 | 30 |
| 85% | 75 | 65 | 50 |
| 21℃ | 50%-70% | 25 | 25 | 25 |
| 80% | 50 | 40 | 30 |
| 85% | 75 | 50 | 40 |
If the humidity exceeds 90%, some cooling water will appeared on
the surface. In this condition, adding the
waterproofing coat or PVC plastic shell if necessary.
Product size of the glass wool pipe
| Density(kg/m3) | Thickness(mm) | Length (mm) | Diameter (mm) |
| 48-80 | 25-90 | 1000,1200 | 18-529 |
Product feature and application of the glass wool pipe
Glass wool pipes are widely used on heat and sound insulation of
ventilating ducts, industrial & civil heat supplying and
all kinds of heating, cooling pipelines.
Applications:
The Fiberglass Pipe Insulation product is made from glass wool,
which is a fireproof material. It is a type of insulation material
that is used to provide heat and sound insulation. It is commonly
used in hot/cold water pipes, HVAC ducts, cooling pipelines, and
ventilation ducts.
The Insulation Pipe Cover is used to cover pipes to prevent heat
loss. This helps to reduce energy costs and improve the efficiency
of the heating system. It is also used to prevent condensation on
pipes, which can cause damage over time.
The Pipe Insulating Fiberglass Material is also used to insulate
HVAC ducts. This helps to prevent the loss of cool air, which can
improve the efficiency of the cooling system. It can also help to
reduce noise from the system, which can be beneficial in commercial
settings.
The Fiberglass Pipe Insulation can also be used to insulate cooling
pipelines. This helps to prevent the loss of cool air, which can
improve the efficiency of the cooling system. It can also help to
prevent condensation on the pipelines, which can cause damage over
time.
Ventilation ducts can also be insulated with Fiberglass Pipe
Insulation. This helps to prevent the loss of cool air, which can
improve the efficiency of the ventilation system. It can also help
to reduce noise from the system, which can be beneficial in
commercial settings.
Packing and Shipping:
Product Packaging:
The Fiberglass Pipe Insulation product is packaged in rolls wrapped
with a plastic film to protect it from dust and moisture. Each roll
is then placed in a corrugated cardboard box with appropriate
labeling and handling instructions.
Shipping:
The Fiberglass Pipe Insulation product is shipped via standard
ground shipping methods. The boxes are stacked on pallets and
securely strapped to prevent any damage during transport. Shipping
labels and handling instructions are placed on each box for easy
identification and proper handling.
FAQ:
Q: What is the brand name of this fiberglass pipe insulation
product?
A: The brand name of this product is Fanryn.
Q: Where is this fiberglass pipe insulation product manufactured?
A: This product is manufactured in China.
Q: Does this fiberglass pipe insulation product come with any
certification?
A: Yes, this product comes with an SGS fireproof certificate.
Q: What is the minimum order quantity for this fiberglass pipe
insulation product?
A: The minimum order quantity for this product is 1*40 ft
container.
Q: How much does this fiberglass pipe insulation product cost?
A: The price of this product is based on the specifications.
Q: What is the packaging detail of this fiberglass pipe insulation
product?
A: The packaging detail of this product is plastic bags.
Q: What is the delivery time for this fiberglass pipe insulation
product?
A: The delivery time for this product is 7-15 work days.
Q: What are the payment terms for this fiberglass pipe insulation
product?
A: The payment terms for this product is 100% TT.
Q: What is the supply ability of this fiberglass pipe insulation
product?
A: The supply ability of this product is 300 containers per month.
